AGA-PROKTO-LIFT Examination chair for proctology x
The AGA-PROKTO-LIFT proctology examination chair was specially developed for examination in the lithotomy position. Thanks to the electric adjustment options and the fold-down seat section, it offers users an excellent examination field.
AGA-PROKTO-LIFT proctology examination chair with electric adjustments
The AGA-PROKTO-LIFT proctology examination chair, Article No.: PRE-1067/EE, has been specially developed for examinations in the lithotomy position. It is equipped with an electric motor for height adjustment and backrest adjustment. The seat section can be unlocked and folded down in two easy steps. The proctology examination chair from AGA Sanitätsartikel also features a low seat height (620 mm).
After the attending physician has moved the back section into the horizontal position using an electric motor and positioned it at the best working height for him using the electric height adjustment, the entire seat section can now be unlocked and folded down in two easy steps. The patient is denied visual contact with the examination field. This ensures the greatest possible relaxation and psychological relief for the patient.
The ergonomic upholstery of the backrest and seat ensures a very high and comfortable sitting and lying position. The integration of a foam wedge in the back section eliminates the need for an additional bolster. A small cutout is incorporated in the pelvic area.
Göpel fastening clamps, Article No.: BKG-600, and a pair of footrests, Article No.: FUS-2000
Features
- The examination chair is equipped with electric height adjustment (830 - 1,030 mm, measured with the backrest horizontal). Due to the precision double square guides, the height adjustment takes place without lateral offset.
- The back section can be lowered from + 54° to 0° using an electric motor.
- The maintenance-free and extremely quiet electric drives used are controlled by foot switches (alternatively - at no extra charge - by hand switch). The adjustment systems are equipped with push-button locks. Motor connection values (each): 230V, 50/60 Hz, 3.7A, 850W, IPX4, v=11mm/s, 10,000N.
- The wide base frame, in conjunction with the pull-out safety support foot and the levelling feet, ensure a secure stand.
- The impact- and scratch-resistant covers of the column and base frame, like all other components, are easy to clean and keep hygienically clean.
- The different upholstery thicknesses of the seat (70 mm) and backrest (95 - 135 mm) give the AGA-PROKTO-LIFT a very high level of sitting and reclining comfort. This is achieved through the use of different, coordinated foam densities.
- There is a small cutout in the backrest cushion in the pelvic area.
- To the side, next to the seat section, on the armrest mounts, there is a pair of standard rails made of stainless steel, dimensions 25 x 10 mm, to accommodate leg support systems.
- The holder of the stainless steel bowl included in the scope of delivery, dimensions 290 x 190 x 45 mm (L x W x H), is fixed above the plastic cover.
- For product safety, there are limit switches in the area of the stainless steel tray and the lower cover, which interrupt the power supply if necessary.
Technical details
| AGA-PROCTO-LIFT | ||
|---|---|---|
| Article number | PRE-1067/EE | |
| Frame | Lacquered | |
| Length back section | 1,050 mm | |
| Length seat section | 350 mm | |
| Width | 580 mm (1,030 mm with armrests) | |
| Entry/seat height | 620 mm | |
| Height adjustment (with horizontal back section) | 830 - 1,030 mm (electric motor) | |
| Upholstery segments | 2 sections | |
| Upholstery thickness seat section | 70 mm | |
| Upholstery thickness back section | 95 - 135 mm | |
| Backrest adjustment | +54°/ 0° (electric motor) | |
| Seat section | can be folded down manually | |
| Load capacity | 130 kg | |
The standard version includes:
- A pair of standard rails attached to the sides of the armrest mounts.
- A pair of armrests.
- A cutout in the backrest upholstery.
- Two safety limit switches for product safety.
- A stainless steel tray with holder.
- A paper roll holder screwed to the back section.
- The floor frame with safety support rod and levelling feet.
- The foot switch.
We offer the coloured lacquer coating of the frames as standard in the following three shades (see frame colour selection card):
- light grey (RAL 7035)
- white aluminum (RAL 9006)
- pure white (RAL 9010).
The high quality finish has a glossy look. It is disinfectant resistant and easy to clean.
Other colours are of course also available. Please let us know the desired RAL colour so that we can find out the corresponding additional costs. Please note, however, that these products are then considered type variants with no right of return.
The artificial leather covers we use are characterized by their tear resistance, durability, longevity and their good cleaning properties as well as their resistance to disinfectants.
We use a (colour) selection from the synthetic leather covers VOWAled Pisa (Vowalon). The colour selection card can be found here.
In addition, we offer you the service of manufacturing the upholstery in other colours or from other synthetic leather manufacturers (type variant). After prior agreement, please send us the relevant references.
The black electrically conductive synthetic leather cover (with equipotential bonding socket on the frame) is available at an additional cost. It is already included in the price of the operating tables and multifunction tables.
Downloads
pdf | 1 MB
Image galleries
PRE-1067/EE, BKG-600, FES-2000
PRE-1067/EE, BKG-600, FES-2000
The photos show the proctology examination chair AGA-PROKTO-LIFT, Article No.: PRE-1067/EE, in the colours:
- Frame: light grey RAL 7035,
- Upholstery: birch
as well as the additional accessories and equipment components:
- Pair of Göpel fastening clamps, Article No.: BKG-600,
- Pair of heel supports, Article No.: FES-2000.
PRE-1067/EE, BKG-600, FES-2000
PRE-1067/EE, BKG-600, FES-2000
The photos show the proctology examination chair AGA-PROKTO-LIFT, Article No.: PRE-1067/EE, in the colours:
- Frame: pure white RAL 9010,
- Upholstery: blue
as well as the additional accessories and equipment components:
- Pair of Göpel fastening clamps, Article No.: BKG-600,
- Pair of heel supports, Article No.: FES-2000.
Accessories & additional options
Article No. | Description |
|---|---|
| BHG-600 | Göpel leg rests (pair), with spherical joints, rods with two 90° bends, chrome-plated, Ø 18 mm, black PU-foam supports, includes straps sewn from synthetic leather with Velcro closure to secure the legs to the shells. A pair of fastening clamps for standard rails is required. |
| BKG-600 | Göpel fastening clamps (pair), for standard rails (dimensions 25 x 10 mm), chrome-plated, for leg holder rods Ø 18 mm. The leg holders can be adjusted in height and tilt using toothed rings and secured with a clamping mechanism. |
| FES-2000 | Heel supports (pair), rods with a 90° bend and half-round loop, chrome-plated, holder for fastening clamps Ø 18 mm. A pair of fastening clamps (Article No.: BKG-600) for standard rails is required. |
| LR/Z-50 | Mobile base with central locking castor system, welded into the base frame (dimensions approx. 1,000 x 450 mm), consisting of 2 swivel and 2 fixed castors, Ø 50 mm, foot pedal with black push-on cap located towards the head end. Retrofitting is not possible. |
OPS-40/A | Standard rails (pair), approx. length 400 mm. |
The components listed above are only a small selection. The following accessories are also available: infusion stand, positioning aids.
Product variants
As a manufacturer, we are able to adapt our products to your individual needs. Below, you will find examples of customer-specific requests we have implemented.
It is possible to equip the proctology examination chair with a synthetic leather cover in a different colour or the backrest upholstery without a cutout. We will be pleased to provide further pricing information upon request.
Questions? Contact us today!
Do you have questions about our products or services? Would like to get to know us? Contact us today, we will be pleased to provide expert advice tailored to your needs.
Product videos
Illustration of the electric backrest adjustment of the AGA-PROKTO-LIFT proctology examination chair, Article No.: PRE-1067/EE, which is equipped with a pair of Göpel fastening clamps, Article No.: BKG-600, and a pair of heel supports, Article No.: FES-2000.
